BSC3110 Brushless motor

SKU: 0101DJ1471
The BSC series FPV brushless motor is our entry-level model, designed to meet the needs of a wide range of customers. It offers an optimal balance between cost effectiveness and uncompromising quality, making it equally suitable for beginners and experienced enthusiasts.
If you are looking for a more durable and aesthetically pleasing motor of the same type, you can choose our FS series.
$0.00 $34.00
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • KV Option:
    900KV-6S
    Please select the information you wantX
Quantity
-
+
  • MAD BSC3110 Brushless motor for 10-11inch long range FPV drone/9-10inch X8 Cinelifter drone
  • MAD BSC3110 Brushless motor for 10-11inch long range FPV drone/9-10inch X8 Cinelifter drone
  • MAD BSC3110 Brushless motor for 10-11inch long range FPV drone/9-10inch X8 Cinelifter drone
  • MAD BSC3110 Brushless motor for 10-11inch long range FPV drone/9-10inch X8 Cinelifter drone
  • MAD BSC3110 Brushless motor for 10-11inch long range FPV drone/9-10inch X8 Cinelifter drone
  • Description

Specification


Motor Model
MAD BSC3110 V1.0
Number of pole pairs
7
Stator
Anticorrosive
Varnished wire Degree
180°C
Motor Size
D:37.1 × 43.9 mm
Magnet Degree
150°C
Degree of Protection
Rain protection Cable Length
250 mm 18# Awg(Black) silicone
Centrifugal Heat Dissipation
Independent Rotor Balance
≤5 mg
Propeller Mounting Holes
M5 Nut
Motor Balance
≤10 mg
Shaft Diameter
IN: 5 mm
Motor Mounting Holes
D:19 M3×4
Bearing 685 *2
Disruptive test
500 V

___________________________________________________________________________________________________________________________


Drawing and mount holes
