4008 EEE Drone Motor - 380KV/600KV

SKU: 0101DJ0305
MAD4008 EEE Elite Drone Motor

Core Performance

 Payload Capacity: 700-1300g/axis
 Propeller Optimization: 14-18" high-load carbon fiber
 Max Thrust: 2700g (2.7kg) per axis
 Weight: 88g (with integrated heat dissipation)

Professional Applications

1. Heavy-Lift Cinematography

  • Safely carries RED V-RAPTOR + 360° gimbal (2.1kg payload)

  • Silent operation for film-set environments

2. Industrial Logistics

  • 5km+ delivery range with 1.5kg cargo

  • Vibration-free for medical transport

3. Defense & Surveillance

  • Stealth operation (IR signature reduced by 40%)

  • EMP-hardened version available

$0.00 $68.00
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • KV Option:
    380KV
    600KV
  • packing way:
    1PC
    2PCS
    Please select the information you wantX
Quantity
-
+
Download
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • 4008 EEE Drone Motor - 380KV/600KV
  • 4008 EEE Brushless Drone Motor
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • 4008 EEE Brushless Drone Motor
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • 4008 EEE Drone Motor - 380KV/600KV
  • 4008 EEE Brushless Drone Motor
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • 4008 EEE Brushless Drone Motor
1/1
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • 4008 EEE Drone Motor - 380KV/600KV
  • 4008 EEE Brushless Drone Motor
  • MAD 4008 EEE brushless motor for the long-range inspection drone mapping drone surveying drone quadcopter hexcopter mulitirotor
  • 4008 EEE Brushless Drone Motor
  • Description
  • 380KV
  • 600KV

About 4008 EEE

 Payload Capacity: 700-1300g/axis
 Propeller Optimization: 14-18" high-load carbon fiber
 Max Thrust: 2700g (2.7kg) per axis
 Weight: 88g (with integrated heat dissipation)

Professional Applications

1. Heavy-Lift Cinematography

  • Safely carries RED V-RAPTOR + 360° gimbal (2.1kg payload)

  • Silent operation for film-set environments

2. Industrial Logistics

  • 5km+ delivery range with 1.5kg cargo

  • Vibration-free for medical transport

3. Defense & Surveillance

  • Stealth operation (IR signature reduced by 40%)

  • EMP-hardened version available



Specification


Motor Model
MAD 4008 EEE V1.0
Number of pole pairs
12
Stator
Anticorrosive
Varnished wire Degree
150°C
Motor Size
D:44.5 × 26.1 mm
Magnet Degree
150°C
Degree of Protection
Rain protection Cable Length
150 mm 18# Awg(Black) silicone
Centrifugal Heat Dissipation
Independent Rotor Balance
≤5 mg
Propeller Mounting Holes
D:12 M3×4
Motor Balance
≤10 mg
Shaft Diameter
IN: 4 mm
Motor Mounting Holes
D:19 M3×4, D:25 M3×4
Bearing NSK 694ZZMC3 *2
Disruptive test
500 V

________________________________________________________________________________________________


Drawing and mount holes

___________________________________________________________________________________________________________________________
